MG-1816V

Standard Equipment

• Vertical offset, cast iron housing
• Input flange for freestanding installation
• Electric GP-valve with manual override
• EC050 Profile module – interface for engagement signals
• Oil cooler for raw water cooling
• Oil strainer and oil filter
• Companion flange/ bolts set
• Mounting brackets

Options

• SAE J617 housing no. 00
• Flexible coupling for 21” flywheel (SAE J620 size 530)
• Harness with single point interface to Twin Disc EC300 control system
• Oil cooler for fresh water cooling
• Monitoring devices to customer’s specification
• Live PTO:
  • SAE J744 size 127-4, 32-4 (SAE “C”, 4-bolt, max. 592 Nm)
• Hydraulic clutchable PTO:
  • SAE J744 size 127-4, 32-4 (SAE “C”, 4-bolt, max. 592 Nm)

INPUT RATINGS – KILOWATTS (KW) (HORSEPOWER (HP))*

For service classification definitions and important notes refer to the Twin Disc Marine Product Guide or contact Twin Disc directly.

* Ratings shown for use with standard right hand rotation engines. The maximum allowable rated engine speed is 2000 rpm.

DIMENSIONS & WEIGHT

* dry weight, including standard equipment

Specifications subject to change without prior notice in the interest of continual product improvement. Contact your local Twin Disc representative for engineering specifications, Survey Society Approvals and Classifications.
